Description
One of the most versatile and popular SK100 jaw sets suitable for the SK100 chuck. The Type C jaws expand into a 70mm recess and have a stepped shoulder for an internal grip onto a 56mm spigot diameter. These given dimensions are when the jaws form a true circle and offer the best grip. There is substantial variation 52mm to 66mm internally and 66mm to 80mm externally. Although the more the jaws expand, the less of a circle they form. The Type C jaws are especially useful for small bowls and end grain work such as boxes and goblets. In addition, a wide range of direct loading accessories are available. These include screw chucks/faceplate drives, faceplate rings and Morse taper carriers. As with all our dovetail jaws they simply bolt onto the Accessory Mounting Jaws. Made from stainless steel to protect against corrosion.
Please note: These jaws are suitable to use with the Axminster Clubman and Evolution SK100 Chucks as well as the Evolution SK114 Chuck.
